Moto Z, Moto Z Force, and Moto Z Play Specs (Official)

moto z force specs

We may earn a commission when you click links to retailers and purchase goods. More info.

The Moto Z and Moto Z Force (Moto Z Play too) are now official! Ready to learn all about these two new, truly modular phones from Motorola and Lenovo? We have lots to share, but to start, we thought we’d just hand out the official specs of each to get you into the dirty details.

As expected, both phones are very high-end, with 5.5-inch Quad HD AMOLED displays, Snapdragon 820 processors, 4GB RAM, 32/64GB internal storage with microSD support, next-gen cameras, and of course, Moto Mod support.

Here you go, dive in.

Moto Z, Moto Z Force, and Moto Z Play Specs

Moto ZMoto Z ForceMoto Z Play
OSAndroid 6.0.1 MarshmallowAndroid 6.0.1 MarshmallowAndroid 6.0.1 Marshmallow
ProcessorQualcomm® Snapdragon™ 820 processor with up to 2.2 GHz CPU Quad-core CPU and Adreno 530 GPU Natural Language Processor Qualcomm® Snapdragon™ 820 processor with up to 2.2 GHz CPU Quad-core CPU and Adreno 530 GPU Natural Language Processor Qualcomm® Snapdragon™ 625 processor up to 2 GHz Octa-Core
CPU with Adreno 506 GPU
RAM4GB4GB3GB
Storage32GB/64GB UFS, microSD Card support (up to 2 TB)32GB/64GB UFS, microSD Card support (up to 2 TB)32GB, microSD Card support (up to 2TB)
DimensionsHeight: 153.3 mm
Width: 75.3 mm
Depth: 5.19 mm
Height: 155.9 mm
Width: 75.8 mm
Depth: 6.99 mm
Height: 156.4mm
Width: 76.4mm
Depth: 6.99mm
Weight136g163g165g
Display5.5” AMOLED
1440p Quad HD (2560 x 1440)
535 ppi
Corning® Gorilla® Glass
5.5” AMOLED
1440p Quad HD (2560 x 1440)
535 ppi
ShatterShield
5.5” Super AMOLED
1080p FHD
(1080 x 1920)
Battery2600mAh
Turbo Charging
3500mAh
Turbo Charging
3510mAh
Turbo Charging
Water resistanceWater repellent nano-coatingWater repellent nano-coatingWater repellent nano-coating
SensorsFingerprint sensor
Accelerometer
NFC
Fingerprint sensor
Accelerometer
NFC
Fingerprint sensor
Accelerometer
NFC
Rear camera13 MP
ƒ/1.8 aperture
Optical Image Stabilization (OIS)
Laser Autofocus
Zero Shutter Lag
Color Correlated Temperature (CCT) flash with dual LEDs
1.12um pixel
21 MP
ƒ/1.8 aperture
Optical Image Stabilization (OIS)
Laser Autofocus
Phase Detection Autofocus (PDAF)
Zero Shutter Lag
Color Correlated Temperature (CCT) flash with dual LEDs
1.12um pixel with Deep Trench Isolation (DTI)
16 MP
ƒ/2.0 aperture
Laser Autofocus
Phase Detection Autofocus (PDAF)
Front camera5 MP
ƒ/2.2 aperture
Wide-Angle lens
Flash
1.4um big pixel for better low light
5 MP
ƒ/2.2 aperture
Wide-Angle lens
Flash
1.4um big pixel for better low light
5 MP
Wide-Angle lens
ConnectivityMoto Mods™ connector
USB-C port for headphones, charging and data transfer
3.5 mm to USB-C headphone port adapter included
Moto Mods™ connector
USB-C port for headphones, charging and data transfer
3.5mm to USB-C headphone port adapter included
Moto Mods™ connector
USB-C port
3.5mm headphone jack
Bluetooth4.14.14.1
Network bandsCDMA (850, 1900 MHz)
GSM / GPRS / EDGE (850, 900, 1800, 1900 MHz)
UMTS / HSPA+ (850, 900, 1900, 2100 MHz)
4G LTE (B1, 2, 3, 4, 5, 7, 13)
CDMA (850, 1900 MHz)
GSM / GPRS / EDGE (850, 900, 1800, 1900 MHz)
UMTS / HSPA+ (850, 900, 1900, 2100 MHz)
4G LTE (B2, 3, 4, 5, 7, 13)
N/A
WiFi802.11 a/b/g/n/ac 2.4 GHz + 5 GHz with MIMO802.11 a/b/g/n/ac 2.4 GHz + 5 GHz with MIMO802.11 a/b/g/n/ac 2.4 GHz + 5 GHz
SIMNanoNanoNano

*These are the specs for the US model, DROID Edition Moto Z variants.

UPDATE: Added Moto Z Play specs on August 31.
