Galaxy Nexus Gets the Teardown Treatment

Waiting for the Galaxy Nexus has been painful enough already, so if you can’t possibly take anymore, then you may want to pass on watching iFixit do their standard teardown. As a device that is almost impossible to come by unless you are willing to fork out $700+ for an unlocked GSM version, this just hurts.

On a positive note, they gave it decent scores for repairability. Well, except for the glass, which they recommend you take good care of as it won’t be easy to replace should you crack it.

Via:  iFixit
